PSA V56.12 VD56.1 ECU Programming Service
Pelican Diagnostics UK offers a specialist PSA V56.12 VD56.1 ECU Programming Service for Peugeot, Citroen, DS, Opel and Vauxhall vehicles fitted with Continental and Vitesco V56.12 and VD56.1 engine control units.
Unlike many earlier PSA ECUs, the Continental V56.12 and VD56.1 ECUs cannot normally be cloned on a true 1:1 basis. Instead, we prepare a compatible replacement ECU by professionally removing the immobiliser system, allowing the replacement ECU to operate in your vehicle without requiring the original ECU.
This provides an effective solution when the original ECU has failed, is physically damaged or is no longer communicating.
- Service: PSA V56.12 VD56.1 ECU Programming
- Price: £200
- Turnaround: Same Day
- While You Wait: Available by appointment in Sleaford
- ECU Types: Continental V56.12 & VD56.1
- Service Includes: Immobiliser Bypass Programming
- Optional Extras: Stage 1 Remap & EGR Delete
How to Order
- Purchase the PSA V56.12 VD56.1 ECU Programming Service.
- Remove your replacement ECU from the donor vehicle.
- Ensure the replacement ECU comes from a vehicle with the same transmission type (manual or automatic).
- Package the ECU securely.
- Include your contact details, vehicle registration and return address.
- Send the ECU to:
Pelican Diagnostics UK
Padley Farm
Drove Lane
Sleaford
Lincolnshire
NG34 8JQ
Most ECUs are programmed and dispatched the same working day.
If you wish to visit us in person, we also offer a while-you-wait ECU programming service in Sleaford by prior appointment.
Why Can’t V56.12 & VD56.1 ECUs Be Cloned?
Unlike earlier Continental and Bosch ECUs, the PSA V56.12 and VD56.1 ECU families use a security architecture that prevents true one-to-one cloning.
Because of this, simply copying the flash and EEPROM contents into another ECU will not normally produce a working replacement.
Instead, our service professionally prepares a compatible replacement ECU by removing the immobiliser system, allowing the ECU to be installed without requiring the original ECU.
This makes it possible to replace an ECU even when the original unit is completely dead or physically damaged.
Continental VD56.1 Immobiliser Bypass
Our Continental VD56.1 Immobiliser Bypass service enables a compatible used ECU to operate without requiring the original immobiliser information.
This is particularly useful when the original ECU has suffered water damage, internal hardware failure or complete loss of communication.
Continental V56.12 Immobiliser Delete
For naturally aspirated 1.2 PureTech engines using the Continental or Vitesco V56.12 ECU, we can prepare a replacement ECU using our specialist immobiliser delete programming process.
This allows a compatible replacement ECU to be fitted without requiring data from the original ECU.
Supported ECU Families
PSA V56.12 (Non-Turbo 1.2 PureTech)
HW 9815037580 (Continental)
- 9829598880
- 9830510980
- 9838397680
- 9840853180
- 9846386780
HW 9858939680 (Vitesco Technologies)
- 9858949880
PSA VD56.1 (Turbocharged 1.2 PureTech)
HW 9815023380
- 9828311880
- 9829492880
- 9829728480
- 9832103580
- 9834609880
- 9838397380
- 9851418180
If your ECU part number is not listed, please contact us with a clear photograph of the ECU label before ordering.
Compatible Vehicles
This ECU family is commonly fitted to PSA/Stellantis vehicles equipped with the 1.2 PureTech engine, including:
- Peugeot 208
- Peugeot 2008
- Peugeot 308
- Peugeot 3008
- Peugeot 5008
- Peugeot Partner
- Peugeot Rifter
- Citroen C3
- Citroen C3 Aircross
- Citroen C4
- Citroen Berlingo
- Citroen C4 SpaceTourer
- DS3 Crossback
- DS4
- Opel Corsa F
- Opel Crossland
- Opel Mokka
- Vauxhall Corsa
- Vauxhall Crossland
- Vauxhall Mokka
Vehicle compatibility should always be confirmed using the ECU hardware number before ordering.
Optional Performance & Software Upgrades
Stage 1 Remap
We can install a bespoke Stage 1 calibration at the same time as programming your replacement ECU, improving performance and drivability. This service is available for an additional charge.
EGR Delete
An EGR delete software solution can also be installed during programming where appropriate. Please contact us for pricing and suitability.
Important Information
- The replacement ECU must come from a vehicle with the same transmission type (manual or automatic).
- This service is intended for compatible replacement ECUs only.
- The original ECU is not required for this service.
- Stage 1 remap and EGR delete are optional extras charged separately.
- If you are unsure which ECU you have, send us a photograph of the label before ordering.
Contact Pelican Diagnostics UK
If you are unsure whether your replacement ECU is compatible, simply send us a clear photograph of the ECU label before ordering. We will confirm compatibility free of charge.
- 📧 Email Pelican Diagnostics
- 📱 Send us a WhatsApp Message
- 📍 Pelican Diagnostics UK
Padley Farm
Drove Lane
Sleaford
Lincolnshire
NG34 8JQ
While-you-wait programming is available by appointment.
Frequently Asked Questions – PSA V56.12 VD56.1 ECU Programming
What is the PSA V56.12 VD56.1 ECU Programming Service?
This service prepares a compatible replacement Continental or Vitesco ECU by removing the immobiliser system, allowing the ECU to be installed into your vehicle without requiring the original ECU.
Why can’t these ECUs be cloned?
Unlike many earlier PSA ECUs, the Continental V56.12 and VD56.1 ECU families use a security architecture that prevents true one-to-one cloning. For this reason, immobiliser bypass programming is the preferred replacement solution.
Do I need to send my original ECU?
No. The original ECU is not required for this service. Only the compatible replacement ECU needs to be sent.
Does the replacement ECU have to come from the same transmission type?
Yes. The donor ECU must come from a vehicle with the same transmission type as yours (manual or automatic). This is essential for compatibility.
How much does the service cost?
The PSA V56.12 VD56.1 ECU Programming Service costs £200.
How long does the programming take?
Most ECUs are programmed and dispatched the same working day after arrival.
Can the service be carried out while I wait?
Yes. We offer a while-you-wait programming service in Sleaford by prior appointment.
Which vehicles use these ECUs?
These ECUs are commonly found in Peugeot, Citroen, DS, Opel and Vauxhall vehicles fitted with the 1.2 PureTech petrol engine.
Can you add a Stage 1 remap?
Yes. We can install a bespoke Stage 1 performance calibration for more power during programming for an additional charge.
Can you disable the EGR system?
Yes. An EGR delete software solution can be added during programming where appropriate. Please contact us for pricing.
How do I know if my ECU is compatible?
Simply send us a clear photograph of the ECU label by email or WhatsApp. We’ll confirm compatibility before you place your order.
Can you program Vitesco ECUs as well as Continental ECUs?
Yes. We support compatible Continental and Vitesco variants within the V56.12 and VD56.1 ECU families.
