Citroen Nemo BSI BCM Fuse Box Replacement Service

Pelican Diagnostics UK provides a specialist Citroen Nemo Fuse Box Replacement Service for vehicles fitted with compatible Delphi BSI / BCM fuse box modules.

This service is designed for customers who have correctly diagnosed a faulty Citroen Nemo BSI, BCM or fuse box and require a programmed replacement module.

You must send us your original BSI so we can extract the vehicle-specific immobiliser, VIN, key and configuration data. We then transfer that data into a compatible used replacement BSI supplied by us.

Our replacement modules are used units that have been tested in the original vehicle before removal.

The original BSI should have diagnostic communication. If the original module is non-communicating, additional recovery work will be required and an extra £50 charge will apply.

• Service: Citroen Nemo BSI / BCM Fuse Box Replacement
• Standard Price: £345
• Non-Communicating Original BSI: Additional £50
• Turnaround: Approximately 1–2 working days after receipt
• Original BSI Required: Yes
• Replacement BSI: Supplied by Pelican Diagnostics UK
• Replacement Condition: Used and tested in the donor vehicle before removal
• Diagnostic Fault Codes Required: Yes for communicating BSI

How to Order

1. Have the vehicle professionally diagnosed and confirm that the BSI / BCM fuse box is faulty.
2. Read and record all diagnostic fault codes stored in the BSI before removing it from the vehicle.
3. Check the complete part number printed on the original Delphi BSI and check if it’s listed below.
4. Place your order for the Citroen Nemo BCM Fuse Box Replacement Service.
5. Remove the original BSI from the vehicle.
6. Include a printed or handwritten list of the fault codes stored in the original BSI.
7. Include your order number in the parcel.
8. Package the BSI securely and send it to:

Pelican Diagnostics UK
Padley Farm
Drove Lane
Sleaford
Lincolnshire
NG34 8JQ

Once received, we extract the available vehicle-specific data from your original BSI and transfer it into a compatible replacement module supplied by us.

The standard turnaround is approximately 1–2 working days after we receive the original BSI and all required information.

Citroen Nemo BSI Replacement

The BSI is a central electronic control module that manages and communicates with many electrical, security and body systems within the Citroen Nemo.

A used replacement BSI cannot normally be fitted directly to another vehicle because it contains immobiliser, VIN, key and vehicle configuration data from the donor vehicle.

Our Citroen Nemo BSI Replacement service transfers the required vehicle-specific information from your original BSI into a compatible replacement module supplied by Pelican Diagnostics UK.

Depending on the module type and condition of the original unit, transferred information may include:

• Immobiliser data
• Key-related security information
• Vehicle Identification Number
• Vehicle configuration
• Body-control settings
• Central-locking configuration
• Lighting configuration
• Relevant synchronisation data

Citroen Nemo BCM Replacement

This service is also suitable for customers searching for Citroen Nemo Body Control Module Replacement or Body Control Module programming.

The terms BCM and BSI are often used interchangeably when customers are referring to the main body electronics and fuse-box control module fitted to the Nemo.

Our service supplies a compatible replacement module and transfers the available vehicle-specific data from your original unit.

Citroen Nemo Fusebox Replacement

The Delphi module fitted to the Citroen Nemo combines important body-control electronics with fuse and power-distribution functions.

If the unit has been correctly diagnosed as faulty, our Citroen Nemo Fusebox Replacement service provides a programmed replacement rather than requiring the customer to source an unknown used module independently.

Our replacement units are used modules that are tested in the original donor vehicle before removal.

Supported Delphi BSI Part Numbers

This service covers compatible Citroen Nemo Delphi BSI / BCM fuse box modules with part numbers including:

• 01358812080
• 01362975080
• 01363580080
• 01364889080
• 01364891080
• 01368890080
• 01368892080
• 01372064080
• 01372879080
• 01377250080
• 01383879080
• 01383881080
• 01384173080

Additional compatible Delphi BSI references may exist. Please send us a clear photograph of the original module label before ordering if your exact part number is not listed.

Original BSI Must Normally Communicate

The original BSI should have diagnostic communication.

Diagnostic communication helps confirm the module identity, fault condition and vehicle configuration before the replacement data is transferred.

If your original BSI does not communicate, we may still be able to recover the required data directly from the module memory.

However, this requires additional work and an extra £50 non-communication recovery charge will apply.

Please contact us before sending a non-communicating module so we can confirm whether recovery is likely to be possible.

Fault-Code List Required

You must provide a list of the diagnostic fault codes stored in the original BSI.

This information is important because several wiring, power-supply and CAN network faults can produce symptoms that appear similar to BSI failure.

Please obtain a diagnostic scan before removing the BSI and include:

• All fault codes stored in the BSI
• Fault-code descriptions where available
• Any communication faults involving the BSI
• Any immobiliser or key-related faults
• Any power-supply or internal module faults

A printed diagnostic report is preferred where possible.

Common Citroen Nemo BSI / BCM Symptoms

• Vehicle will not start
• Immobiliser active
• Keys not recognised
• No communication with the BSI
• Central locking faults
• Exterior lighting faults
• Indicators not working correctly
• Electric window faults
• Wiper faults
• Horn faults
• Random electrical problems
• Fuse-box related electrical faults
• Battery drain
• CAN communication faults
• Water-damaged BSI
• Replacement BSI requires programming

These symptoms do not automatically confirm a faulty BSI. Wiring, power supplies, earth connections, CAN network faults and other components must be checked before ordering.

Replacement Citroen Nemo BCM Supplied by Pelican Diagnostics UK

You do not need to source your own replacement BSI for this service.

We supply a compatible used replacement module and transfer the available vehicle-specific data from the customer’s original BSI.

Our used replacement modules are tested in the donor vehicle before removal to confirm correct operation prior to programming.

This helps avoid the uncertainty associated with purchasing an unknown or untested BSI from an online marketplace or vehicle dismantler.

What Is Included in the £345 Service?

• Compatible used replacement Delphi BSI / BCM fuse box
• Replacement module tested in the donor vehicle before removal
• Data extraction from the customer’s original BSI
• Immobiliser data transfer where supported
• VIN and configuration transfer
• Key-related data transfer where supported
• Programming of the replacement BSI
• Return of the original and programmed replacement modules
• Approximately 1–2 working day turnaround

If the original BSI is non-communicating, the additional recovery charge is £50.

Correct Diagnosis Is Essential

The vehicle must be correctly diagnosed before ordering.

A replacement BSI will not repair unrelated faults such as:

• Damaged wiring
• Corroded connectors
• Poor power supplies
• Poor earth connections
• Blown fuses caused by another fault
• CAN network problems
• Faulty ignition switches
• Faulty keys
• Defective door modules
• Faulty lighting circuits
• Vehicle battery or charging-system faults

This is why a fault-code list from the original BSI is required before programming the replacement unit.

Will the Replacement BSI Be Plug and Play?

The replacement BSI is programmed using the available data extracted from your original module.

In most successful programming cases, the replacement unit should be ready for installation without further immobiliser or key programming.

Some vehicles may still require:

• Diagnostic fault-code clearing
• Configuration checks
• Window or central-locking relearning
• Additional vehicle-level coding
• Initialisation of certain vehicle functions

Any additional on-vehicle work is not included unless agreed separately.

What Is Not Included?

• Vehicle diagnosis
• Vehicle wiring repairs
• BSI removal or installation
• Repair of unrelated vehicle faults
• Key supply
• On-vehicle coding unless separately arranged
• Repair of vehicle wiring or CAN network problems
• Repair of other modules connected to the BSI

Important Information

• Standard price: £345.
• Non-communicating original BSI: additional £50.
• The original BSI must be sent to us.
• A diagnostic fault-code list must be supplied.
• The original BSI should have diagnostic communication.
• The replacement BSI is supplied by Pelican Diagnostics UK.
• The replacement module is used and tested in the donor vehicle before removal.
• Turnaround is approximately 1–2 working days after receipt.
• Vehicle compatibility and part number must be confirmed.
• The vehicle must be correctly diagnosed before ordering.
• Additional charges may apply for difficult or damaged data recovery.
• Programming cannot correct unrelated wiring or network faults.

Why Choose Pelican Diagnostics?

• Specialists in Citroen BSI and BCM programming
• Compatible replacement BSI supplied by us
• Replacement modules tested in the donor vehicle before removal
• Professional immobiliser and configuration data transfer
• Support for communicating and selected non-communicating modules
• Fast 1–2 working day turnaround
• UK postal service
• Trade and private customers welcome
